UGRID 2-Way Tap
$20.99 USD
The UGRID 2-Way Tap is a professional-grade BCV series outdoor directional tap that splits signal from the main cable line to multiple subscriber drops while maintaining downstream signal levels. Built for CATV and HFC networks, it covers 5–1218 MHz and is DOCSIS 3.1 / OFDM compatible, ready for 1.2 GHz upgrades.
- Built for outdoor plant: IP68 waterproof die-cast housing rated -40 °C to +60 °C.
- Protected: 6 kV surge protection (IEEE-compliant).
- Serviceable: AC/RF bypass switch.
- Options: Tap value (dB): 4dB, 8dB, 11dB, 14dB, 17dB, 20dB, 23dB.
Specifications
| Frequency range | 5–1218 MHz |
|---|---|
| Tap value (dB) | 4dB, 8dB, 11dB, 14dB, 17dB, 20dB, 23dB |
| Series | BCV |
| Compatibility | DOCSIS 3.1 / OFDM |
| Surge protection | 6 kV (IEEE-compliant) |
| Housing | IP68 waterproof die-cast |
| Operating temperature | -40 °C to +60 °C |
| AC/RF bypass switch | Yes |
| Impedance | 75 Ω |
Need volume pricing? Request a bulk quote.
